This lab bestows an overview about the power electronic circuits employed in controlling and maintenance of power supply. This lab is equipped with various kits which include inverters, rectifiers, cyclocontrollers, AC voltage regulators, choppers etc.
| S.NO | Equipments |
|---|---|
| 1 | SCR |
| 2 | MOSFET & IGBT |
| 3 | UJT Firing Unit |
| 4 | TRIAC Phase Control Unit |
| 5 | SCR Half Controlled & Fully Controlled Three Phase Converter |
| 6 | SCR single Phase Cyclo Converter |
| 7 | SCR Parallel Inverter |
| 7 | SCR Series Inverter |
| 8 | Resonant DC - DC Converter |
| 9 | Step Down & Step Up MOSFET Based Chopper |
| 1 | Switched Reluctance motor drive |
| 1 | IGBT based 3 phase SVPWM inverter. |
The lab focus on technical implementation issues of classical control theory in the frequency domain and modern control theory in the state-space. Design and implementation for this course is done using MATLAB / Simulink software and hardware for control of the plants. Various measurements involved and the latest instrumentation technologies are experimented in the lab. This lab acquaints the students to design and scrutinize a controller for the productiveness
| S.NO | Equipments |
|---|---|
| 1 | Maxwell’s Bridge |
| 2 | Wheatstone’s Bridge |
| 3 | LVDT |
| 4 | Anderson’s Bridge |
| 5 | Schering Bridge |
| 6 | ADC |
| 7 | DAC |
| 8 | Synchro transmitter and receiver |
| 9 | Instrumentation Amplifier |
| 10 | Temperature sensor |
| 11 | Pressure measurement kit |
| 12 | Displacement measurement kit |
| 13 | Strain Gauge and Flow measurement kit |
The basic wiring lab expose the basic concepts , knowledge and imparts hands on training to the students on the electrical wiring systems, like symbols, components , safety measures , wiring methods etc. The knowledge gained through the lab helps the students to do and build their own electrical wiring practices as they are associated in the day to affairs and life routines. This lab assists the basic wiring of inter disciplinary projects.
| S.NO | Equipments |
|---|---|
| 1 | Single Phase Energy Meter |
| 2 | Megger |
| 3 | General purpose PCB |
| 4 | Logic gates |
The lab is updated with software namely MATLAB. The lab is utilized by the UG students to enhance the Power System Analysis and Stability studies. The laboratory acts as a predominant source for completing their projects. Equipments: MATLAB 2015b, Laser Printer, Dot Matrix printer and Compilers.
| S.NO | Equipments |
|---|---|
| 1 | MATLAB 2015b |
| 2 | Laser Printer |
| 3 | Dot Matrix Printer |
| 4 | Compilers |
